· Larger radiation disk – compared to the KBE5L, the EPX radiation disk is 20% larger, allowing the EPX to radiate infrared heat further and wider. · High/low output control – the EPX has an output control switch that enables users to choose between a high or low heat output, optimizing fuel-efficiency. · Longer operational time – with a 15 gallon tank, the EPX is able to operate continuously for 20 hours on the low heat output setting and 15 hours on the high heat output setting, enabling the EPX to operate all day long without refueling. · Built-in fuel preheater – the EPX is equipped with a fuel preheater to prevent fuel from gelling and congealing during extremely low temperatures, further optimizing fuel-efficiency. · Thermostat connector – the EPX is equipped with an external thermostat connector (thermostat sold separately). · Advanced monitoring system – color indication lamps are equipped in the main control panel. Not only does this make the mode of operation available, but prompt troubleshooting is now possible by attaining precise information via various safety devices

Below are practical applications of how EPX can serve you and your needs: Heating source for a large warehouse, factory or plant Warming up machines and personnel Winter construction – heats up materials, machines, and working sites Surface drying Personal heating Outdoor projects Drying of paint and adhesives Asphalt and concrete preparation Sporting events Large garages and body shops

Below are relevant safety features for the EPX: · Overheat prevention - to prevent malfunction, the EPX has an automatic shutdown system that activates when the main chamber reaches abnormally high temperatures. · Tip-over protection - the EPX will automatically shut down when it is tipped over or receives a strong impact (bump). · High-voltage detection - to prevent malfunction, the EPX will automatically shut down when it detects abnormally high voltage conditions. · Photocell flame monitor - the flame monitor will shut down the EPX if it detects an abnormal flame in the main chamber. · After power outage - in the event of power loss the EPX will not automatically restart to prevent fire or undetectable accidents when the power is restored.

EPX SCHEMATICS AND PARTS LISTS EPX OWNERS' MANUAL EPX BROCHURE EPX MAINTENANCE MANUAL

Radiant heat – the KBE5L (2-step) produces infrared, radiant heat that evenly and directly penetrates the objects and bodies around it. Unaffected by air movement – since the KBE5L (2-step) solely utilizes infrared, radiant heat, it is unaffected by air movement, such as wind and drafts. Heat transfer - the KBE5L (2-step) generates infrared heat directly to the object without any air movement creating a dust free comfortable environment. Odorless – the KBE5L (2-step) is equipped with a state-of-the-art clean and complete combustion system that produces no odor and no smoke in operation, maximizing user comfort. Fuel-efficient – the KBE5L (2-step)'s state-of-the-art combustion chamber further enables virtually 100% fuel-to-energy conversion, optimizing fuel-efficiency. Portable – the KBE5L (2-step) equipped with wheels, virtually enabling users to move it any space in need of heat.

Below are practical applications of how the KBE5L (2-step) can serve you and your needs: Factory, plant, workshop Outdoor projects Construction sites Drying of paint and adhesives Asphalt and concrete preparation Sporting events Garages and body shops

Below are relevant safety features for the KBE5L (2-step): Overheat prevention - to prevent malfunction, the KBE5L (2-step) has an automatic shutdown system that activates when the main chamber reaches abnormally high temperatures. Tip-over protection - the KBE5L (2-step) will automatically shut down when it is tipped over or receives a strong impact (bump). High-voltage detection - to prevent malfunction, the KBE5L (2-step) will automatically shut down when it detects abnormally high voltage conditions. Photocell flame monitor - the flame monitor will shut down the KBE5L (2-step) if it detects an abnormal flame in the main chamber. After power outage - in the event of power loss the KBE5L (2-step) will not automatically restart to prevent fire or undetectable accidents when the power is restored.

KBE5L (2-STEP) SCHEMATICS AND PARTS LISTS KBE5L (2-STEP) OWNERS' MANUAL KBE5L (2-STEP) BROCHURE KBE5L (2-STEP) & KBE5S SERVICE MANUAL

Radiant heat – the KBE5S produces infrared, radiant heat that evenly and directly penetrates the objects and bodies around it without air movement creating a dust free comfortable environment. Uneffected by air movement – since the KBE5S solely utilizes infrared, radiant heat, it is uneffected by air movement, such as wind and drafts. Odorless – the KBE5S is equipped with a state-of-the-art clean and complete combustion system that produces no odor and no smoke in operation, maximizing user comfort. Fuel-efficient – the KBE5S state-of-the-art combustion chamber further enables virtually 100% fuel-to-energy conversion, optimizing fuel-efficiency. Portable – the KBE5S equipped with wheels, enabling users to move it to virtually any space in need of heat.

Below are practical applications of how the KBE5S can serve you and your needs: Factories, plants, workshops Outdoor projects Construction sites (including indoor use) Drying of paint and adhesives Asphalt and concrete preparation Sporting events Garages and body shops

Below are relevant safety features for the KBE5S: Overheat prevention - to prevent malfunction, the KBE5S has an automatic shut down system that activates when the main chamber reaches abnormally high temperatures. Tip-over protection - the KBE5S will automatically shut down when it is tipped over or receives a strong impact (bump). High-voltage detection - to prevent malfunction, the KBE5S will automatically shut down when it detects abnormally high voltage conditions. Photocell flame monitor - the flame monitor will shut down the KBE5S if it detects an abnormal flame in the main chamber. After power outage - in the event of power loss the KBE5S will not automatically restart to prevent fire or undetectable accidents when the power is restored.

KBE5S SCHEMATICS AND PARTS LISTS KBE5S OWNERS' MANUAL KBE5S BROCHURE KBE5S SERVICE MANUAL

Dual-heating system – much like its smaller sister unit (the DAYSTAR) the MPX utilizes advanced technology that combines both convectional heat (i.e. heated air), as well as radiant heat, allowing it to maximize heat output in large and small settings. Larger radiation disk – compared to the DAYSTAR, the MPX is equipped with a larger radiation disk that improves combustion efficiency by 13%, allowing the MPX to provide heat to a wider and further radius. High/low output control – the MPX has an output control switch that enables users to choose between a high or low heat output, optimizing fuel-efficiency. Longer operational time – with a 6.6 gallon tank, the MPX is able to operate continuously for 15.7 hours on the low heat output setting and 13.7 hours on the high heat output setting, enabling the MPX to operate all day long without refueling. Thermostat connector – the MPX is equipped with an external thermostat connector (thermostat sold separately).

Below are practical applications of how the MPX can serve you and your needs: Body shop, garage Factory, plant, workshop Outdoor projects Drying of paint and adhesives Asphalt and concrete preparation Construction sites (including indoor use) Sporting events

Below are relevant safety features for the MPX: Overheat prevention - to prevent malfunction, the MPX has an automatic shutdown system that activates when the main chamber reaches abnormally high temperatures. Tip-over protection - the MPX will automatically shut down when it is tipped over or receives a strong impact (bump). High-voltage detection - to prevent malfunction, the MPX will automatically shut down when it detects abnormally high voltage conditions. Photocell flame monitor - the flame monitor will shut down the MPX if it detects an abnormal flame in the main chamber. After power outage - in the event of power loss the MPX will not automatically restart to prevent fire or undetectable accidents when the power is restored.

MPX SCHEMATICS AND PARTS LISTS MPX OWNERS' MANUAL MPX BROCHURE MPX SERVICE MANUAL

· Dual-heating system – the first of its kind, the DAYSTAR utilizes advanced technology that combines both convectional heat (i.e. heated air), as well as, radiant heat, allowing it to maximize heat output that is ideal in spot heat scenarios. · Odorless – the DAYSTAR is equipped with a state-of-the-art clean and complete combustion system that produces no odor and no smoke in operation, maximizing user comfort. · Fuel-efficient – the DAYSTAR's state-of-the-art combustion chamber further enables virtually 100% fuel-to-energy conversion, optimizing fuel-efficiency. · Portable – the DAYSTAR is lightweight– 40 lbs– and compact, making it the ideal unit to use for spot heating.

Below are practical applications of how the DAYSTAR can serve you and your needs: Patios & porches Factories, workshops, & warehouses Outdoor activities (e.g. sports, games, camping) Construction sites (including indoor use) Drying of paint and adhesives Asphalt and concrete preparation Sporting events Garages and body shops

Below are relevant safety features for the DAYSTAR: Overheat prevention - to prevent malfunction, the DAYSTAR has an automatic shutdown system that activates when the main chamber reaches abnormally high temperatures. Tip-over protection - the DAYSTAR will automatically shut down when it is tipped over or receives a strong impact (bump). High-voltage detection - to prevent malfunction, the DAYSTAR will automatically shut down when it detects abnormally high voltage conditions. Photocell flame monitor - the flame monitor will shut down the DAYSTAR if it detects an abnormal flame in the main chamber. After power outage - in the event of power loss the DAYSTAR will not automatically restart to prevent fire or undetectable accidents when the power is restored.

DAYSTAR SCHEMATICS AND PARTS LISTS DAYSTAR OWNERS' MANUAL DAYSTAR BROCHURE DAYSTAR MAINTENANCE MANUAL

· Far-infrared waves - as opposed to the traditional VAL6 units, the X5 utilizes the longest wavelength of heat: far-infrared waves. This wavelength produces a gentle, luxurious heat, ideal in environments with many persons. · Enclosed flame - the X5 utilizes an enclosed flame; this, coupled with the far-infrared heat waves, creates a heater that can be touched with a bare-hand, maximizing user safety. Hotspots have now been eliminated with X5’s balanced heat. Safety and Proximity have been maximized without compromising on heating performance. · Larger unit face - the X5 has the largest face of any of the val6 units, creating a larger heating area. · Low operating noise - the X5 is the quietest radiant heater on the market, almost completely inaudible. · Built-in thermostat - the X5 is the only VAL6 to have a built-in thermostat; it adjust itself between 5 heat settings, never fully turning off to maintain temperature while also maximizing fuel consumption. Equipped with a state-of-the-art combustion control system, X5 will intelligently modulate intensity in order to maintain the target temperature with enhanced precision. · Efficient: World-Class VAL6 efficiency has advanced even farther with X5. Leading to greater fuel savings.

Below are practical applications of how the X5 can serve you and your needs: Body shop, garage Office space Outdoor restaurant patio spaces Wineries / wedding venues

Below are relevant safety features for the X5: Overheat prevention - to prevent malfunction, the X5 has an automatic shutdown system that activates when the main chamber reaches abnormally high temperatures. Tip-over protection - the X5 will automatically shut down when it is tipped over or receives a strong impact (bump). High/low-voltage detection - to prevent malfunction, the X5 will automatically shut down when it detects abnormal voltage conditions. Flame monitor - the flame monitor will shut down the X5 if it detects an abnormal flame in the main chamber. After power outage - in the event of power loss the X5 will not automatically restart to prevent fire or undetectable accidents when the power is restored.

FIR X5 SCHEMATICS AND PARTS LISTS FIR X5 OWNERS' MANUAL FIR X5 SERVICE MANUAL FIR X5 BROCHURE

· Clean combustion – the efficiency of the GN5/GP5 II premixed gas combustion system means the GN5/GP5 II produces less than 1 ppm of carbon monoxide– 10-20 times less co than typical forced-air (torpedo-style) heaters. · Quiet operation – the premixed gas combustion system further allows the GN5/GP5 II to produce minimal operation noise. The GN5/GP5 II produces approx. 60 db, compared to typical forced-air (torpedo-style) heaters that produce upwards from 75 db. · Adjustable angle – the GN5/GP5 II radiation disk is conveniently adjustable up to a 90 degree vertical angle.

BELOW ARE PRACTICAL APPLICATIONS OF HOW THE GN5/GP5 CAN SERVE YOU AND YOUR NEEDS: Construction sites Warehouses Job site Outdoor projects Factories, plants, workshops Garages and body shops

Below are relevant safety features for the GN5/GP5 II: Overheat prevention - to prevent malfunction, the GN5/GP5 II has an automatic shutdown system that activates when the main chamber reaches abnormally high temperatures. Tip-over protection - the GN5/GP5 II will automatically shut down when it is tipped over or receives a strong impact (bump). High-voltage detection - to prevent malfunction, the GN5/GP5 II will automatically shut down when it detects abnormally high voltage conditions. Photocell flame monitor - the flame monitor will shut down the GN5/GP5 II if it detects an abnormal flame in the main chamber. After power outage - in the event of power loss the GN5/GP5 II will not automatically restart to prevent fire or undetectable accidents when the power is restored.

GN5/GP5 SCHEMATICS AND PARTS LIST GP5 II SCHEMATICS AND PARTS LIST GN5/GP5 OWNER'S MANUAL GP5 II OWNER'S MANUAL GN5/GP5 SERVICE MANUAL GP5 II SERVICE MANUAL GN5/GP5 II BROCHURE

· Fuel-efficient – the HOTGUN’s state-of-the-art combustion chamber enables virtually 100% fuel-to-energy conversion, optimzing fuel-efficiency. · Longer operational time – with a 14.3 gallon tank, the HOTGUN is able to operate continuously for 15 hrs, enabling the HOTGUN to operate all day without refueling. · Quiet operation – unlike other forced-air (torpedo-style) heaters, the HOTGUN’s remarkable technology achieves a quiet combustion of 69 db, compared to typical forced-air (torpedo-style) heaters that produce noises upwards of 75 db. · Portable – the HOTGUN is lightweight and equipped with wheels, virtually enabling users to move it any space in need of heat.

Below are practical applications of how the HOTGUN can serve you and your needs: Warehouse Factories, plants, workshops Outdoor projects Construction sites (including indoor use) Drying of paint and adhesives Asphalt and concrete preparation Sporting events Garages and body shops

Below are relevant safety features for the HOTGUN: Overheat prevention - to prevent malfunction, the HOTGUN has an automatic shutdown system that activates when the main chamber reaches abnormally high temperatures. High-voltage detection - to prevent malfunction, the HOTGUN will automatically shut down when it detects abnormally high voltage conditions. Photocell flame monitor - the flame monitor will shut down the HOTGUN if it detects an abnormal flame in the main chamber.

HOTGUN 125NA SCHEMATICS AND PARTS LISTS HOTGUN 125NA OWNERS' MANUAL HOTGUN 125NA SERVICE MANUAL HOTGUN 125NA BROCHURE

· Economic efficiency – the RKF uses very little power consumption because it creates cool air through natural principles. Therefore, the RKF can drastically save users on operating costs, compared to traditional air conditioning systems. · No exhaust heat – the RKF produces comfortable, natural cool air and its huge airflow carries a long way. The RKF never emits exhaust heat, like traditional air conditioners, because it is not equipped with a compressor. · Earth-friendly – due to its minimal power consumption and lack of exhaust output, the RKF is an energy-saving product, that also contributes to the reduction of CO2 in the environment. In addition, the RKF does not utilize any harmful refrigerant gas, such as Freon. · Variable wind direction – the auto-swing louver mechanism enables wind to blow in the range of 80 degrees horizontally. In addition, the user can direct the wind 30 degrees vertically. · Portable – the RKF is equipped with caster wheels for easy moving. · Adjustable blower speeds – the RKF features an easy touch button selector for high, medium, and low blower settings, maximizing user comfort in all environments.

Below are practical applications of how the RKF 506A can serve you and your needs: · Workplaces (e.g. production lines, factories and warehouses) · Cooling down mechanical equipment and products · Indoor or outdoor events/parties · Outdoor restaurant venues · Sports sidelines to cool down athletes

Below are relevant safety features for the RKF 506A: · Water shortage detection - the RKF 506A is equipped with a mechanism to shut down the machine if water supply runs low. · Overheat prevention - to prevent malfunction, the RKF 506A has an automatic shut down system that activates when the motor reaches abnormally high temperatures.

RFK 506-A SCHEMATICS AND PARTS LISTS RKF 506-A OWNERS' MANUAL RKF 506-A SERVICE MANUAL RFK 506-A BROCHURE

Radiant heat is generated through infrared light waves. Val6 heaters heat up to the temperature required to emit infrared light waves. When infrared light leaves the surface of an object, radiant heat is created and travels to the surfaces of other cooler objects.

Radiant heat is... 1. Unaffected by air-movement. Since radiant heat is created through infrared light waves, rather than heated air, radiant heat allows you to heat desired bodies and objects that will be unaffected by air movement, such as wind, much like traditional forced-air heaters (e.g. torpedo heaters) would be. The radiant heat created by VAL6 heaters essentially penetrates evenly just like heat from the sun itself would. 2. Odorless and smokeless. The high temperatures in which fuel has to be heated to emit the infrared light waves that generate radiant heat creates a clean, complete combustion system that produces less than 1 part per million (ppm) carbon monoxide. This state-of-the-art combustion system makes VAL6 heaters virtually odorless and smokeless, further contributing to the comfortable environments they create. 3. Fuel-efficient. Again, the extremely high temperatures needed to convert fuel to infrared waves and radiant heat creates a virtually 100% fuel-to-energy conversion that maximizes the use of the fuel you put into VAL6 heaters. This makes VAL6 heaters the most fuel-efficient heaters on the market.

Diesel #1, #2, or Kerosene can be use in the VAL6 heaters.

“SHIZUOKA SEIKI warrants that its heaters and component parts will be free from defects in material and workmanship for a period of 24 months from date of purchase, when properly installed, operated, and maintained in accordance with the installation and Maintenance Instructions, safety guides and labels contained with each unit. If any component proves defective in either material or workmanship during the limited warranty period, Shizuoka Seiki, at its option, repair the defective part or equipment, or replace it with a new part or equipment.” Note: normal “wear and tear” is not covered by the warranty. It is necessary and normal to periodically replace such parts as the fuel nozzle and filter element. Please contact us to request a Warranty Claim Form.

For the most widely sold VAL6 heater models, the model name and serial number information is located on a label on the plastic burner cover which may be black or yellow depending on the heater model. Once you locate this information it would be a good idea to record it on the owner's manual. Your VAL6 heater can continue to provide heat for 20 years or more in which time the label may fade or wear away. You will need the model name and serial number if you need to order replacement parts.

After heater season is over: Please drain your VAL6 heater's fuel tank. Replace the fuel filter and nozzle to keep your heater in good condition and ready for next season. Wipe off the eye of the flame monitor with a soft dry cloth or cotton tipped applicator. Use compressed air to blow the dirt/dust out of the fan motor. Check the insulation cone/cylinder for deep cracks that go through to the outer metal cone/cylinder. Replacement may be necessary if deep cracks are present. All new VAL6 heaters come with a standard maintenance kit, including the appropriate fuel filter and nozzle, as well as a nozzle wrench for your VAL6 heater. If you need to order more supplies, please click here or click the Parts tab under Products on the main page.

The drain plug for the VAL6 heaters is located on the underside of the fuel tank. Using a wrench, remove the plug to drain the fuel. It is recommended this is done at the end of each winter season. The exception is the DAYSTAR VAL6 heater. There is no drain plug, the fuel tank can be removed and inverted to drain or simply leave it running until it runs out of fuel. For all VAL6 heaters, the tank should be drained periodically and cleaned of debris that can accumulate from dirty fuel. This debris will clog your fuel nozzle and filter element.

First, identify your VAL6 heater's model. EPX, KBE5L, KBE5S, KBE5S-V The fuel filter assembly is located below the burner box on the bottom right of the unit. Having a cup/bowl ready to catch any excess fuel, unscrew the filter bowl. The red filter will slide on/off. Once the fuel filter is exchanged, reassemble the filter bowl. MPX, DAYSTAR, FIR-2000 Unscrew the copper fuel line from the inlet port of the fuel pump, then pull the rubber gasket up from the fuel tank, exposing the fuel filter. Slide the fuel filter off and replace with a new one. Once complete, reinsert the gasket and reattach the fuel line. GN5/GP5 II The GN5/GP5 II utilize a fixed air filter. The only maintenance needed in respect to the "filter" will be blowing the air filter out at the end of the season to remove any debris. FIR 2000, FIR 1300 The fuel filter is attached to the filter assembly which is inserted in the fuel tank next to the fuel tank cap. Remove the filter assembly from the tank to replace the filter. FIR X5 Unscrew the copper fuel line from the inlet port of the fuel pump, then pull the rubber gasket up from the fuel tank, exposing the fuel filter which attaches to the suction pipe assembly. Slide the fuel filter off and replace with a new one. Once complete, reinsert the gasket and reattach the fuel line. *For service assistance, please call or email Shane at 304.890.7831, shane@southeastval6.com

First, identify your VAL6 heater model. Refer to the videos below to watch a step-by-step guide on how to change your VAL6 heater model fuel nozzle: EPX, KBE5L, KBE5S, KBE5S-V Using a 13mm wrench, loosen the 3 nuts behind the burner cone; the entire burner assembly will tilt back exposing the nozzle. Using the nozzle wrench provided in your maintenance kit, unscrew the nozzle, and replace with appropriate nozzle for your unit (refer to unit's maintenance guide for appropriate nozzle size). Tighten nozzle down with nozzle wrench, then replace burner assembly and replace screws to reattach to burner cone. MPX, DAYSTAR Using a phillips head screwdriver, remove burner cover. Then, unscrew the copper fuel line from the inlet port of the fuel pump. Remove the two lead wires from the overheat sensor, located above the fuel pump. Using a 10mm, wrench remove the two nuts at the top of the burner assembly and one at the bottom. The entire burner assembly will then tilt back, exposing the nozzle, replace appropriate size nozzle. Reassemble unit in reverse order. GN5/GP5 *For service assistance, please call or email Shane at 304.890.7831, shane@southeastval6.com. FIR 2000, FIR1300, FIR X5 *For service assistance, please call or email Shane at 304.890.7831, shane@southeastval6.com.

First, identify your VAL6 heater model. KBE5L, KBE5S, KBE5S-V, DAYSTAR, GN5, GP5 II Underneath the burner box on the KBE5L, KBE5S, KBE5S-V, and DAYSTAR VAL6 heaters, there are two white wires that are snapped together to make a loop. The connection is sealed in a tight plastic sleeve. Disconnect these two wires, you may need to carefully cut the plastic sleeve in half if it won’t pull apart. Plug the wires in to the corresponding female/male ends on your thermostat. It is recommended you remove the thermostat and reconnect the two wires when moving any VAL6 heater outdoors, as the thermostat is not water-resistant. EPX, MPX The EPX and MPX VAL6 models come equipped with an external thermostat port, located on the control panel of your heater. To use, remove the cover on the external port, then connect your thermostat. It is recommended you remove the thermostat and recover the external port when moving any VAL6 heater outdoors, as the thermostat, nor uncovered port is water-resistant.
